Tag Archives: Exchange 2013

Exchange 2013 CU17 and Exchange 2016 CU6

On June 27, 2017 Microsoft has released its quarterly updates for Exchange 2013 and Exchange 2016. The current version is now at Exchange 2013 CU17 and Exchange 2016 CU6. Typically I don’t pay that much attention to this, all new developments seem to be for Office 365 and very little developments for on-premises Exchange deployment. But this time there are some interesting things I’d like to point out.

A couple of days before the release of Exchange 2016 CU6 Microsoft blogged about Sent Items Behavior Control and Original Folder Item Recovery. With the Sent Items Behavior Control, a message that’s sent using the Send As or Send on behalf of permission is not only stored in the mailbox of the user that actually sent the message, but a copy is also stored in the delegator mailbox sent items. This was already possible for shared mailboxes, but now it’s also possible for regular mailboxes (like manager/assistant scenarios).

The Original Folder Item Recovery feature is I guess on of the most requested features. In the past (before Exchange 2010) when items were restored after they were deleted, they were restored to their original location. With the Dumpster 2.0 that was introduced with Exchange 2010 this was no longer possible, and items were restored to the deleted items folder. In this case the items had to be moved manually to their original location. With the introduction of the Original Folder Item Recovery the restore of deleted items again takes place in the original folder.

Continue reading Exchange 2013 CU17 and Exchange 2016 CU6

Setting Calendar permissions right after mailbox creation

Customer is running Exchange 2013 with approx. 2500 mailboxes. When looking at calendars and sharing information through the availability service only the availability (free, busy or tentative) is shown. No details are shown by default.

Customer now request to publish more information so that users that want to schedule a meeting can see the details of other user’s appointments. This should not only be configured for existing users, but new users should receive this setting directly when provisioned.

For example, when configuring this for a user called Kim Akers (kima@exchangelabs.nl) for all users you can use the following Exchange PowerShell command:

Set-MailboxFolderPermission kima:\Calendar -User Default -AccessRights Reviewer

When scheduling a meeting with Kim Akers I can now see her appointment details in Outlook, and I can open the appointment to see all details (read-only) of this appointment as shown in the following two screenshots:



Note. Check the Set-MailboxFolderPermission article on Microsoft TechNet for all details regarding the permissions that can be assigned.

Continue reading Setting Calendar permissions right after mailbox creation

REGISTRY_FILTER_DRIVER_EXCEPTION (swin1.sys)

A blue screen on your Windows box, is there anyone that has never seen it? One place you don’t want to see this is on your Exchange server.

While upgrading 3 Exchange 2013 CU12 servers for a customer to Exchange 2013 CU15 I experienced a blue screen while updating the UM components, resulting in the following screen:


A quick search on Google (search on “swin1.sys”) revealed that McAfee was the culprit. I’m not a fan of installing (file level) anti-virus software on an Exchange server, and IMHO it’s not needed when you have a properly secured environment.

I was successful installing CU15 on the Edge Transport servers earlier, but it turned out that these servers were not running McAfee software.

Uninstalling the McAfee agent is not a big deal, just a matter of deselecting the server in the EPO console. The McAfee Solidifier didn’t want to uninstall, not via the EPO console nor via Add/Remove Programs.

According to the McAfee knowledgebase article KB75902 you can uninstall this software using a command line with the following commands:

sc stop scsrvc
sc delete scsrvc
sc delete swin
"\Program Files (x86)\McAfee\Common Framework\Mctray.exe" unloadplugin=scormcpl.dll
del /Q "C:\WINDOWS\system32\drivers\swin.sys"
rmdir /S /Q C:\Solidcore
rmdir /S /Q "C:\Program Files\McAfee\Solidcore"
rmdir /S /Q "C:\ProgramData\McAfee\Solidcore"
reg delete "HKLM\SOFTWARE\Network Associates\ePolicy Orchestrator\Application Plugins\SOLIDCOR5000_WIN" /f
reg delete "HKLM\SOFTWARE\Classes\Installer\Features\4E9BD2348836F234A9BD168E87F25439" /f
reg delete "HKLM\SOFTWARE\Classes\Installer\Products\4E9BD2348836F234A9BD168E87F25439" /f
reg delete "HKLM\SOFTWARE\Microsoft\Windows\CurrentVersion\Uninstall\{432DB9E4-6388-432F-9ADB-61E8782F4593}" /f

After running these commands and a reboot I was able to finalize the installation of Exchange 2013 CU15.

Updated Exchange Server Role Requirements Calculator

The Exchange Server Role Requirements Calculator which you need for designing a proper Exchange 2013 or Exchange 2016 on-premises environment has been updates, currently the calculator is at version 8.4.

Some new functionality is added to this version:

  • Added support for ReplayLagMaxDelay
  • Added support for SafetyNetHoldTime in CreateDAG.ps1

And seven bug fixes in this version:

  • Improved the DAG auto-calculation results display to highlight deployment configuration in both datacenters
  • Fixed an issue that prevented DAG auto-calculation in single site DAG deployments
  • Fixed a SPECInt2006 validation issue with DAG auto-calculation
  • Fixed a bug with the DAG auto-calculation with Active/Passive deployments
  • Fixed conditional formatting issues with the transaction log table
  • Removed data validation from certain unused cells on the Input tab
  • Fixed bug in calcNumActiveDBsSF formula

The requirements calculator can be downloaded here: https://gallery.technet.microsoft.com/Exchange-2013-Server-Role-f8a61780

More information:

POP3, IMAP4, Get-Service and Startup Type

When installing lots of Exchange servers, automation with PowerShell scripting can be very useful. This will ensure you get a consistent platform, and it reduces the chance of errors and misconfiguration.

For a customer I had to deploy 38 Exchange 2013 servers, and they were using POP3 and IMAP4 as well, so these services need to be installed on all Exchange 2013 servers.

By default, POP3 and IMAP4 are not running on an Exchange 2013 server, and the service Startup Type is set to Manual.

You can change the startup type to automatic using the Services MMC snap-in, but for 38 Exchange 2013 servers this isn’t funny anymore.

You can use the Get-Service cmdlet in Windows to retrieve information regarding Windows services, for example:

Get-Service –ServiceName MSExchangePOP3

Or add the Format-List option to get more detailed information:


You can use the –ComputerName option to retrieve similar information from another server:


There’s all kind of interesting information here, but the most important thing, the Startup Type information is missing here.

To retrieve the Startup Type information you can use the Get-WmiObjectcmdlet and filter on the service name, for example:

Get-WmiObject -Class Win32_Service -Property StartMode -Filter "Name='MSExchangePOP3'"

Please note the single and double quotes in the Filter option!


Again, you can use the –ComputerName option to retrieve this information from another server.


Note. On an Exchange 2013 (and Exchange 2016) server POP3 and IMAP4 are actually two services. There’s the CAS component (MSExchangePOP3) and the Mailbox server component (MSExchangePOP3BE). These services need to changed independently. The same is true for the IMAP4 service.

You can write a small script to create an overview of all Exchange servers with the Startup Type of all POP3 service, this will look something like:

$Servers = Get-ExchangeServer
ForEach ($Server in $Servers){
$Computer = $Server.Name
$Object = Get-WmiObject –Class Win32_Service –Property StartMode –Filter “Name=’MSExchangePOP3’”
Write-Host $Computer,$Object.StartMode
}

You can change the Startup Type of the POP3 service using the Set-Service command:

Set-Service –ServiceName MSExchangePOP3 –StartupType Automatic

And you can use the-ComputerName to change the Startup Type of a service running on another Server:

Set-Service –ServiceName MSExchangePOP3 –StartupType Automatic –ComputerName EXCH02

More information:

Use PowerShell to Find Non-Starting Automatic Services – https://blogs.technet.microsoft.com/heyscriptingguy/2012/12/18/use-powershell-to-find-non-starting-automatic-services/

Get-Service – https://technet.microsoft.com/en-us/library/hh849804.aspx

Set-Service – https://technet.microsoft.com/en-us/library/hh849849.aspx
