Exchange 2019 on Windows Server Core disk management

When installing an Exchange 2019 Edge Transport server on Windows 2019 Server core I realized there’s no disk management MMC snap-in, so all disk configuration needs to be done using PowerShell.

For this blogpost I added a 20GB disk to my Windows 2019 Server Core server which I want to use as a D:\ drive for my SMTP queue.

You can use the Get-Disk command to retrieve the server’s disk configuration, and you can pipe this disk object into the Initialize-Disk command to bring it online and assign a new partition:

Get-Disk –Number 1 | Initialize-Disk –PartitionStyle GPT New-Partition –DiskNumber 1 –UseMaximumSize

Initialize-Disk

By default, Windows installs on drive C:\ and the DVD is mounted as drive D:\. You can use the Get-WmiObject and the Set-WmiInstance commands to assign it a different drive letter, for example drive Z:\

Get-WmiObject -Class Win32_volume -Filter ‘DriveType=5′ | Select -First 1 | Set-WmiInstance -Arguments @{DriveLetter=’Z:’}

The next step is to assign drive letter D:\ to the newly added disk:

Add-PartitionAccessPath -DiskNumber 1 -PartitionNumber 2 –AccessPath “D:\”

And finally format it using NTFS file system and a block size of 64KB:

Get-Partition –Disknumber 1 –PartitionNumber 2 | Format-Volume –FileSystem NTFS –NewFileSystemLabel “Queue” -AllocationUnitSize 65536 –Confirm:$false

format-disk

Now you can continue with the standard installation procedure for an Exchange 2019 Edge Transport server (which does not differ from an Exchange 2013 or Exchange 2016 Edge Transport server)

DNS Suffix Windows 2019 Server Core

While preparing a Windows 2019 Core server for an Exchange 2019 Edge Transport server I had to set the FQDN of the server. The server name itself is not difficult, you can change this using the SCONFIG tool, but you cannot change the DNS suffix using SCONFIG.

For changing the DNS suffix on a Windows 2019 Core you can use the NETDOM, the REG.EXE or PowerShell:

netdom computername %computername% /makeprimary:%computername%.exchangelabs.nl

or when using the computer name itself:

netdomain computername AMS-EDGE01 /makeprimary:AMS-EDGE01.exchangelabs.nl

To add the registry key needed for the DNS suffix (HKLM\SYSTEM\CurrentControlSet\Services\Tcpip\Parameters\Domain\NV Domain) you can also use the REG.EXE tool:
reg.exe add HKLM\SYSTEM\CurrentControlSet\services\Tcpip\Parameters /v “NV Domain” /t REG_SZ /d “exchangelabs.nl” /f

Or you can use PowerShell:

New-ItemProperty -Path “HKLM:\ SYSTEM\CurrentControlSet\services\Tcpip\Parameters\” -Name “NV Domain” -PropertyType REG_SZ -Value “exchangelabs.nl”

New-ItemProperty DNS Suffix

Reboot the server, run IPCONFIG /ALL and you’ll see the DNS suffix. The server can now be used for installing Exchange 2019 Edge Transport server.
ipconfig all



set-msoldirsyncenabled not available

Now with Microsoft moving from the old MSOL to AzureAD PowerShell commands (see my blogpost on Azure Active Directory PowerShell v2), you get new features but (unfortunately) things are starting to disappear as well.

In the past you could use Azure AD PowerShell to enable or disable directory synchronization using the Set-MsolDirSyncEnabled cmdlet. During a recent lab deployment, I found out that this cmdlet is no longer available. In fact, not a single Msol cmdlet is available anymore, try Get-Command *msol* and nothing is returned.

To get more information regarding Azure AD you can use Get-Command *Set-AzureAD*. This reveals enough information, but nothing that points to directory synchronization.


When logging on to the Azure Portal (of the newly created Office 365 tenant) it is obvious that Azure AD Connect sync is not enabled, as shown in the following screen shot:


When you dive deeper into the Azure Active Directory section of the Azure Portal, you can see that synchronization has never run, and that password sync is disabled (which makes sense at this point):


Nowhere can an option be found to enable directory synchronization, as you had to do previously before configuring directory synchronization. The only option you have is to download Azure AD Connect, using the following link: http://www.microsoft.com/en-us/download/details.aspx?id=47594

So, let’s give it a try….

Logon to the new Azure AD Connect server, download Azure AD Connect and start the wizard. The Express installation will perform the following steps:

  • Configure synchronization of identities in the current AD forest of <your domain>
  • Configure password synchronization from on-premises AD to Azure AD
  • Start an initial synchronization (I’ll get back on this later in this blogpost)
  • Synchronize all attributes
  • Enable auto upgrade


Enter the administrator credentials of your Office 365 tenant and your on-premises Active Directory and you’re ready to go:


One remark: I unchecked the Start the synchronization process when configuration completes option, and checked the Exchange hybrid deployment checkbox.

The reason I unchecked the synchronization process is that I do not want to synchronize all objects from my on-premises Active Directory to Azure Active Directory, but I only want to synchronize objects from the OU=Accounts container in my Active Directory domain.

If you want more information regarding the Exchange hybrid deployment and the write-back of properties from Azure AD to your on-premises Active Directory, you can visit the following Microsoft article:

Exchange Server Hybrid Deployments – https://technet.microsoft.com/en-us/library/jj200581(v=exchg.150).aspx

When the configuration is complete you can click the Exit button and you’re good. Please note that at this point no synchronization has taken place yet.


To make a selection based on Organizational Unit for synchronization you can start the Synchronization Service Manager (miisclient.exe) which can be found in the C:\Program Files\Microsoft Azure AD Sync\UIShell directory.


Click on the Connectors tab, and select the Connector (sometimes referred to as Management Agent) for your on-premises Active Directory. Click properties and select Configure Directory Partitions. Here you can select which containers should be used for synchronization to Azure Active Directory, as can be seen in the following screenshot:


Start the initial Azure AD synchronization using the Start-ADSyncSyncCycle -Policytype Initial command and wait for the results:


This will trigger the initial synchronization to Azure Active Directory, but won’t do any subsequent sychronizations. Use the Set-ADSyncScheduler -SyncCycleEnabled $true command to run periodic synchronizations.

When checking the Azure Portal, you can see that user objects are now synchronized from the on-premises Active Directory to Azure Active Directory, as shown in the following screenshot:


Summary

So, in short, previously you had to enable directory synchronization manually using the Set-MsolDirSyncEnabled command (or using the wizard in Office 365), but this is no longer the case. When running Azure AD Connect, directory synchronization in your tenant will automatically be enabled.

Exchange 2016 CU9 and Exchange 2013 CU20 released

On March 20, 2018 Microsoft has released two new quarterly updates:

  • Exchange 2016 Cumulative Update 9 (CU9)
  • Exchange 2013 Cumulative Update 20 (CU20)

There aren’t too many new features in these CUs. The most important ‘feature’ is that TLS 1.2 is now fully supported (most likely you already have TLS 1.2 only on your load balancer). This is extremely supported since Microsoft will support TLS 1.2 ONLY in Office 365 in the last quarter of this year (see the An Update on Office 365 Requiring TLS 1.2 Microsoft blog as well).

Support for .NET Framework 4.7.1, or the ongoing story about the .NET Framework. The .NET Framework 4.7.1 is fully supported by Exchange 2016 CU9 and Exchange 2013 CU20. Why is this important? For the upcoming CUs in three months (somewhere in June 2018) the .NET Framework 4.7.1 is mandatory, so you need these to be installed in order to install these upcoming CUs.

Please note that .NET Framework 4.7 is NOT supported!

If you are currently running an older CU of Exchange, for example Exchange 2013 CU12, you have to make an intermediate upgrade to Exchange 2013 CU15. Then upgrade to .NET Framework 4.6.2 and then upgrade to Exchange 2013 CU20. If you are running Exchange 2016 CU3 or CU4, you can upgrade to .NET Framework 4.6.2 and then upgrade to Exchange 2016 CU9.

Schema changes

If you are coming from a recent Exchange 2013 CU, there are no schema changes since the schema version (rangeUpper = 15312) hasn’t changed since Exchange 2013 CU7. However, since there can be changes in (for example) RBAC, it’s always a good practice to run the Setup.exe /PrepareAD command. For Exchange 2016, the schema version (rangeUpper = 15332) hasn’t changed since Exchange 2016 CU7.

As always, check the new CUs in your lab environment before installing into your production environment. If you are running Exchange 2013 or Exchange 2016 in a DAG, use the PowerShell commands as explained in my earlier EXCHANGE 2013 CU17 AND EXCHANGE 2016 CU6 blog.

More information and downloads

Azure Active Directory PowerShell v2

Maybe you’ve already heard about Microsoft Graph and the Graph API. Microsoft Graph is the way resources in the Microsoft cloud are connected to each other. The Graph API is an API you can use to access Microsoft Graph, and browse (or traverse) through all the resources.


You can use the Graph API when building your own applications, but Microsoft is moving all their apps, tools etc. to the Graph API as well.

Azure Active Directory PowerShell v2 is moving from the Azure AD API’s to the Graph API as well. This automatically implies that Azure AD PowerShell v2 comes with new cmdlets and new options. The output of these cmdlets should be similar of course (creating a new domain, group or user in Azure Active Directory), but that these cmdlets are in no way compatible with the old Azure AD PowerShell.

Unfortunately, you have no choice then moving to Azure AD PowerShell v2. The existing PowerShell v1 will of course be supported for quite some time as it is impossible for everyone to convert their processes, cmdlets, scripts etc. from one version to another.

Note. We’ve seen similar when Microsoft moved from Azure ASM to Azure ARM. It has been taken years for Microsoft to move everything to ARM, so no worries for end-of-support scenarios anytime soon.

Installing Azure AD PowerShell v2 is easy, just install the module using the Install-Module command. This will download the module from the PowerShell repository.

Install-Module AzureAD

When executed you will receive a notification about an untrusted repository. Click [Y] or [A] to continue. The module will be downloaded and installed.




You can use the following commands to store the credentials of your Office 365 and/or Azure tenant administrator account and use it to login to Azure Active Directory:

$AzureADCred = Get-Credential &lt;your tenant admin&gt;<p>Connect-AzureAD -Credential $AzureADCred


You’ve now installed the Azure Active Directory PowerShell v2 module and are logged on to your tenant. If you want to retrieve a list of all new v2 PowerShell commands use can use the Get-Command command:

Get-Command *AzureAD*


In future blogposts I will continue with the Azure AD PowerShell v2 module.
